Plumbing work galleryReal photos from our sites.
Every photo on this page is from a Swastik Buildtech site: the work behind the wall and the finished result.
Behind the wall
FinishedChoose an area
Tap an area to see its photos. Tap any photo to view it larger.
This kind of work is part of almost every site we do: on Golf Course Road, Golf Course Extension Road, Sohna Road, Dwarka Expressway and in Central Gurugram, and across Delhi NCR too. See the areas we serve
Bathing area
Shower areas, from the concealed lines behind the wall to the finished fittings.
Want this in your bathroom?
This kind of work is part of almost every site we do, across Gurugram and Delhi NCR.
Wash basin area
Wall-mounted basin mixers and counter basins, from the concealed body in the wall to the finished fitting.
Wall-mounted basin mixer
Want this in your bathroom?
This kind of work is part of almost every site we do, across Gurugram and Delhi NCR.
Geyser area
Water heater points, from the concealed connections to the installed geyser.
Horizontal water heater
Want this in your bathroom?
This kind of work is part of almost every site we do, across Gurugram and Delhi NCR.
Water softener & filter
Water softeners and sand filters for homes and societies, connected with neat CPVC piping and multiport valves.
Want it looked after every year?
This kind of work is part of almost every site we do, across Gurugram and Delhi NCR.
Solar water heater
Rooftop solar water heaters with evacuated tubes, connected to the building with hot and cold water piping.
Want this on your project?
This kind of work is part of almost every site we do, across Gurugram and Delhi NCR.
Behind the wall
Concealed plumbing photographed before plastering. Tap the numbers to see what we check.
- 1Checked with a spirit level
The valve bodies are set level before the wall is plastered, so the final fittings sit perfectly straight.
- 2Concealed valve body
Fixed firmly at the planned position before the wall is closed.
- 3Neat crossover loop
The line loops cleanly around the other pipe instead of crossing it at an odd angle.
- 4Clean bends and joints
CPVC lines with square bends and properly made solvent-cement joints.
- 5Protected pipe
This pipe is wrapped with tape to protect it before plastering.
- 1Protective valve cover
A cover keeps the concealed valve clean and safe while the wall is plastered.
- 2Outlet plugged
Open outlets stay sealed with a plug until the fixtures are fitted.
- 3Pipes tied in place
Lines are tied so they do not shift while the wall is plastered.
- 4Straight vertical runs
Plumb, straight runs are neater and easier to locate later.
- 5Protected pipe
This line is wrapped with tape to protect it before plastering.
- 1Mixer body with protective cap
The concealed body is centred, and its cap stays on until the finish trim is fitted.
- 2Union connections
Unions on the inlets make the valve easier to service in future.
- 3Symmetrical inlets
Inlet lines are brought in neatly and evenly from both sides.
- 4Pipes clamped
Clamps hold the pipes firmly to the wall before plastering.
- 5Outlet plugged
The outlet stays plugged until the shower or spout is fitted.
Want this on your project?
This kind of work is part of almost every site we do, across Gurugram and Delhi NCR.
